Records for Tillotson’s Minatare, Neb., job include specs, give total cost picture

Story by Ronald Ahrens, photos by Kristen Cart

The small concrete elevator in Minatare, Nebr., is the oldest we have visited that was built by Tillotson Construction. After forming in 1938 as a partnership between Reginald and Joe Tillotson, and with their sister Mary also involved, Tillotson Construction built their first concrete elevator in 1939 and another in 1940. Both were in Oklahoma. But 1941 was a big year with five elevators, a pair of which, also in Oklahoma, were quite large with capacity of 212,000 bushels.

The Minatare elevator in this town in eastern Scotts Bluff County was built according to a plan original to the site. Company records show it had a side driveway with bins over the drive, 11 bins, two tanks with capacity of 16,000 bushels and two with capacity of 15,300 bushels.

The elevator and dryer stand idly by the Minatare rail siding.

Construction details show 690 cubic yards of reinforced concrete were used and 27.5 tons of reinforcing steel.

Gross weight when loaded was 3,377 tons.

The drawform walls rose 100 feet, and the cupola’s dimensions were 15 feet wide, 28 feet long, and 18 feet high. The center of the head pulley was at 116.16 feet above the ground.

This was a single-leg elevator. The head pulley was 48 x 14 x 3 7/16 inches, which was an inch and a quarter wider than the boot pulley. A 15-horse Ehrsam motor turned the head at 48 rpm. Leg capacity isn’t listed.

What is listed, though–and we find this quite exciting!–is information about costs that the company records exclude after World War Two.

The grand total for Minatare was all of $19,578.04 less commission. Here is a breakout of individual categories:

  • Labor: $5,526.83 at the rate of 35 cents per hour straight time and 60 cents for overtime
  • Cement: $2,590.75
  • Sand (30,000 cubic yards): $1,149.60
  • Reinforcing steel (J-rods, wires & nipples): $2,156.01
  • Lumber: $835.03
  • Machinery: $4,172.77
  • Structural Steel: $$772.53
  • Electrical materials: $155.07
  • Doors & windows: $47.36
  • Painting & waterproofing: $65.83
  • Hardware (bolts, nails, etc.): $169.71
  • Equipment Expense (depreciation, rentals, etc.): $246.29
  • Freight (not included above F.O.B. job): $509.51
  • W.H. tax & Ins.: $723.82
  • Miscel. (overhead, job office, plans, bond, etc.): $457.11

Double-checking the numbers, we find the total of 19,578.22. That’s 18 cents higher than the amount stated in the records.

The co-op office attached to the elevator. Grain weight and quality were assessed here.

What we would like to learn next is how Tillotson Construction landed those early jobs like Minatare. And how much was the commission?

We have the sense there are more records available at the locations to help us learn about our grandfathers’ grain elevators. One of these days, we want to visit Goltry, Newkirk, Douglas, and Medford, Okla., just for starters, to learn what we can about those early days.

A tour of Odebolt, Iowa, reveals much about its historic Mayer-Osborn elevator

The Mayer-Osborn elevator in Odebolt, Iowa was one of the few they built that was never painted white.

The Mayer-Osborn elevator in Odebolt, Iowa was one of the few they built that was never painted white.

Story and photos by Kristen Cart

Recently, I took a detour quite out of the way of the Interstate system to visit the town of Odebolt, where my grandfather, William Osborn, built an elevator. I introduced the western Iowa site in a previous post.

Tim pointed out the bin diagram for the elevator.

Tim pointed out the bin diagram for the elevator.

Tim Gunderson made a great tour guide for the site and the town. The part-time elevator worker and full-time farmer wanted to know the age of the Mayer-Osborn elevator as much as I did. It was an old stepped-headhouse, slip-formed, concrete elevator in the style of earlier Mayer-Osborn efforts in McCook, Neb., and Roggen, Colo., and it stood at the center of a sprawling grain operation.

During our inspection of the elevator, we saw tantalizing details that indicated mid-1950s architecture. The mechanical workings (never altered during renovation) recalled intact examples of my grandfather’s previous work. The reliance on mechanical controls was a clue to the early design.

The big wheel controls grain distribution to the bins. It is a simple, elegant solution to a mechanical problem.

The big wheel was a simple, elegant (mechanically speaking), way to distribute grain to the bins.

Most of the standard clues to an elevator’s age were absent or misleading. The manhole-covers inside the elevator bore no date (usually they do), but perhaps Mayer-Osborn ordered a quantity of manhole-covers, embossed with only their name, toward the end of their operations in the mid-1950s.

The "blue leg" is an original, painted in Mayer-Osborn's standard color

The “blue leg” is original, painted in Mayer-Osborn’s standard trim color

The elevator showed no signs of exterior paint. This was a deviation from the norm, and a sign of more modern construction. I began to suspect the elevator was built after Mayer-Osborn ceased operations, using left-over parts. But answers would come from elsewhere, in town, where we looked for a witness to the elevator’s beginnings.

Our next stop was the library, where we perused daily papers from 1955. As I thumbed through a number of pages, I realized I didn’t know which year to search, much less what day. It would not be an effective use of time–I could only stay a couple of hours before heading to the next elevator on my route.

Tim was looking up friends who might know more. We crossed the street to the bank, where Renae Babcock referred us to an insurance office nearby. There we met Dick Duffy, and he told us a story.

Dick Duffy was in high school when the elevator went up–he thought it was in 1954 or 1955. On dark evenings while spending time with a friend (who graduated in 1955), he watched construction activity at the brightly lit elevator site. Flood lights illuminated every corner of the scene. He recalled that the concrete pour went day and night, and as he shared some personal reminiscences, he said, “You won’t write that, will you?”

Dick Duffy shares memories of 1954

Dick Duffy shared memories of 1954.

One detail he did mention, which tightened the time range further, was a tragedy that happened during the fall of the year the elevator was built. It was 1954 when a young boy was run over by a car and killed in town. Dick thought the child’s name was Kevin Bower. The event was traumatic–it fixed the time of the year’s events forever in the minds of residents.

“Was that the year that boy Kevin died?”

“Yes, I believe it was.”

We have pegged the construction date for the Odebolt elevator to the spring and summer of 1954. At the same time, the Mayer-Osborn elevator at Blencoe, Iowa, was built under supervision of my dad’s brother, Dick. The concrete there was improperly mixed and two days of work were wasted. Shortly afterward, Mayer-Osborn ceased operations, and Grandpa Bill Osborn left Denver behind and returned to Nebraska to his family.

Heartfelt thanks go to the residents of Odebolt–those mentioned and unmentioned here–for their kindness and helpfulness. I don’t think I have ever experienced a friendlier reception while pursuing historical elevators.

The town deserves a good historical expose that goes beyond the scope of the blog. It is a town with a fascinating history, great civic pride, and a strong sense of identity from its days as a ranch property to today. I hope to learn all about it and to come back again.IMG_2256



Abraham Tillotson, who fought in the Revolution, was too wealthy for a pension



The Tillotson family was adept at seizing opportunities such as the demand for grain storage in the 1940s.

The Tillotsons were adept at seizing opportunities, such as the demand for grain storage in the 1940s.

Story by Kristen Cart

Abraham Tillotson, the direct ancestor of Charles H. Tillotson, the builder of wooden grain elevators, joined the Continental Army in 1775 and served for more than a year, earning the grateful thanks of our new nation. After the war he became a farmer, but in old age he asked for a pension based upon his service.

In 1818, Congress authorized pension payments for veterans who had fallen on hard times. It was not until the 1830s that the pensions were offered to widows and orphans. Veterans had to prove their service (inconveniently, the British burned all of the Revolutionary War service records held in Washington during the War of 1812). To that end, they had to produce witnesses to their service. They also had to prove that they were poor and unable to care for themselves.

Sometimes, veterans navigated the rules adroitly and obtained their pensions without much trouble, and retired in relative comfort. Sometimes it took years for them to prove their service. And sometimes, many letters flew back and forth before a grudging pittance was approved–enough to usher the elderly veteran quietly to his grave.

Abraham’s pension file, digitally preserved at Fold3.com, provides an amusing counterpoint to the usual, sorrowful packet of letters.

Page 4-1

On Oct. 9, 1819, Abraham Tillotson, a resident of Casenovia, aged 63, appeared before the Court of Common Pleas in Madison County, New York to make his statement of service. He said he enlisted on Dec. 18, 1775, serving in Capt. Levi Wells’ company, Col. Samuel Wylie’s Regiment, in the 22nd Connecticut Line of Continental Establishment. He was discharged at Fishkill, New York, on Jan. 1, 1777. He had fought in the Battles of Flatbush and Long Island, and at the taking of General Burgoyne. He produced a witness to his service in the person of Henry Champion.

According to the court, Abraham’s statement averred that “he is in reduced circumstances and stands in need of assistance from his country for support.” Apparently, Abraham had no trouble getting onto the pension rolls. His trouble came later.

Abraham’s consternation was evident in the letter he wrote on July 11, 1822:

“… I am informed of the suspension of my pension until I produce satisfactory evidence doing away [with] information received at the War Department of my being ‘worth more than five to six thousand dollars.’ From whatever source this information may have been received, it is totally false, without a shadow of foundation, and must have been engendered in the brain of some malicious and corrupt villain. The information indirectly charges me with false swearing and if I knew the malicious informant, I would (as I did the enemies of my country) chastise him for his audacity, old and infirm as I am.”

He went on, protesting his honesty: “In obtaining the bounty of my country, for which I fought and bled (when, probably, your informant was in his cradle), I pursued an honest correct course and such as prescribed by the love of my country…”

He was up against a formidable stack of evidence to the contrary.

The Honorable E. Litchfield was the first to alert authorities to Abraham’s wealth, after he learned that Abraham Tillotson was worth between five and six thousand dollars. Abraham’s pension was suspended from that date, Dec. 6, 1821.

Page 42

Further investigation yielded more.

“State of New York,

We, the subscribers, freeholders and inhabitants of the town of Cazenovia in the County of Madison and of the town of Pompey in the County of Onondaga and state aforesaid, do certify–that we have been acquainted with Abraham Tillotson of said Cazenovia for a number of years–that we have lived and do still live [as] neighbors to him–that we have considered him one of our most independent farmers, one who has money to loan, whenever he can obtain extravagant interest, or dispose of some property at a high price and obtain good security–that his property year before last was valued by the assessors at about eighteen hundred dollars–and further we consider him the said Tillotson abundantly able to support himself and family–and under the existing law authorizing the payment of pensions do not think him entitled to a pension–given under our hands this 21st day of August 1822.

Rufus Lyon, Joseph Atwell, Daniel Allen, James McCluen, Joseph Atwell Jr., Elijah Hill.”

Whoops.

Other affidavits contain the same sort of accusations. Needless to say, Abraham never recovered his pension. He died two years later in 1824. His widow tried to reinstate his pension in the 1830s, also to no avail.

Page 33

Abraham offered to pay Rufus Lyon, one of his accusers, to testify in his favor

So began a Tillotson tradition of success and wealth, of sharp business dealings, and of a willingness to partner with the U.S. Government when advantageous–a perfect template for the private/public partnership that became the grain elevator boom of the 1940s and 50s. I would be quite proud of such a clever ancestor, notwithstanding a bit of shading of the truth. His neighbors (debtors?) might not quite agree.



The demise of Mayer-Osborn Construction remains an enduring puzzle

Audrey, Gerald, William and Alice Osborn, ca. 1950

Audrey, Gerald, William and Alice Osborn, circa 1950.

Story by Kristen Cart

Some mysteries are not meant to be solved. Perhaps it is a natural outgrowth of my grandmother’s tight-lipped discretion where evil tidings were concerned. I can remember the disapproving purse of her lips if I broached the wrong topic–it was wise to move on.

Albert Skoog as a boy

Albert Skoog as a boy

Alice Christoffersen married William Osborn in the 1920s. All anyone in our family could know about those times was conveyed in the pleasant images of a young couple goofing around by the lake and fishing. In later pictures you could see the pained expression of a long-suffering middle-aged woman, but her concerns were private, at least when they brought bad memories to mind.

My dad, Jerry Osborn, was quite amazed to find he had a deceased great-uncle, whose name had never been spoken in front of him. Alice Christoffersen’s maternal uncle, Albert Skoog, died young from injuries sustained in a horrific automobile crash when she was a young woman. The story was relegated to the darkest recesses, never to be mentioned again.

“Albert Skoog Dies from Effects of an Auto Accident

Had Lived Nearly Ten Months with a Broken Back

After living nearly ten months with a broken back, during which time he suffered untold agony, Albert Skoog, 42, formerly and employee of the Fremont Stock Yards, died at the home of his sister, Mrs. James L. Christoffersen, south of Fremont. Death was due to injuries sustained in a automobile accident on the Lincoln Highway about a mile east of Fremont last October….”

The article went on to describe the accident and his medical treatment. He died in the family home of Alice’s parents.

This image was found among Grandma's pictures. It was the car her uncle wrecked in an ultimately fatal accident.

The wreck fatally injured Albert Skoog, who died months later from a broken back. Grandma had this photo of the car in an album that once belonged to her mother.

No stone marks his grave. It took many years to locate pictures of him, preserved by a different branch of the Christoffersen clan. Images of the wrecked car also survived, tucked away in Grandma’s photo album. But such things were not discussed in my grandmother’s world.

Another side of Grandma’s personality was not so discrete–she would tell stories that put others in a bad light when she thought she could gain favor for herself. This habit got worse as she aged, and by the time she passed on at age 98, family members believed awful stories about each other because of things she said.

We have tried, without success, to verify Grandma’s story of why my grandpa, William Osborn, got out of the elevator business. Perhaps she invented it. We have no way to tell.

Mayer-Osborn elevator at McCook, Neb. during a family visit, ca 1950. This elevator was the first of its type, a model for the later Blencoe elevator.

Mayer-Osborn elevator at McCook, Neb. during a family visit, circa 1950. This elevator was a prototype for the Blencoe elevator.

Dad never had an inkling about why his dad quit (except that he heard in whispers not intended for him) until Mom started poking around. Grandma told her the story, apparently in a fit of pique. Details were fuzzy, and by now, not well remembered. There’s hardly more to it than speculation. But that one glimpse was the only information we ever got. Otherwise, it “wasn’t discussed,” as Dad put it.

Mom says an elevator was built, and very shortly thereafter, failed. She variously used the terms “collapse,” “explosion,” and “fire.” But the two things she was pretty consistent about were the facts that the concrete mix was wrong because the crew had shorted the materials (possibly for financial gain), and that the collapse occurred as soon as the elevator was filled with grain for the first time. That is all she remembers from what Grandma told her.

Dad says his father was out of the business by 1955. Dad remembers that his dad had come home to Fremont, Neb., from Denver, Colo., the home base of his business, that summer when he should have been on the job. He thinks that his dad was blamed for the failure–Bill’s partner, Gene Mayer, apparently went on without him. But that is all we have.

We don’t know where it happened and haven’t found a newspaper story. We know a large terminal elevator collapsed that year in Fargo, N.D., but we discovered the identity of that builder and it wasn’t Mayer-Osborn. There were whispers about an elevator that had a bad headhouse around Linn, Kan., or Bradshaw, Neb., which might have been his, but that story hasn’t been verified or dated.

The Blencoe, Iowa elevator built by Mayer-Osborn

The Blencoe, Iowa elevator built by Mayer-Osborn

The only story I can verify is the tear-down and restart of the Mayer-Osborn elevator in Blencoe, Iowa. The concrete mix was wrong there, and it cost a few days and quite a lot of money to correct. Could that relatively mundane event in 1954 have created a rift between the partners, Bill Osborn and Gene Mayer? Was the tale of a more dramatic accident simply angry gossip from my grandmother?

Until we know more, it is a skeleton yet to be found, buried in a very deep closet.





A mystery unfolds at the Tillotson elevator of Blencoe, Iowa

This elevator is attributed to the Tillotson Construction Company of Omaha, but evidence points elsewhere

This elevator is attributed to the Tillotson Construction Company, but evidence points elsewhere.

Story and photos by Kristen Cart

In an earlier post, we showed that the elevator built by the Tillostson Construction Company in the northwest Iowa town of Blencoe had a structural failure prior to completion. A photo provided by Tim Tillotson showed that the concrete slumped over the driveway after the slip-form pour had progressed considerably past the point of failure. Construction would have halted there. The question of how the elevator was completed was never answered.

In the company records we have, the specifications log ended by 1956, while the company continued to build elevators beyond that date. So later records are lost to us. Tim Tillotson estimated that this mishap occurred in about 1955. I discovered, on review, that Blencoe was not in the specifications at all. Why?

A photo of the manhole cover on the rail side of the elevator could provide the answer. It is not typical for Tillotson elevators to have exterior manhole covers on elevators of this type, so the existence of these was a little surprising. More shocking was the identity of the company that placed them.

"Grain Storage Const. Co, 1959, Council Bluffs, Iowa" is embossed on the manhole cover

“Grain Storage Const. Co, 1959, Council Bluffs, Iowa” is embossed on the manhole cover.

The Grain Storage Construction Company of Council Bluffs, Iowa, is not familiar to us. It may be the company called in to repair the damage when the failure occurred.

We don’t know if Tillotson Construction was fired on the spot. But it is also possible that Tillotson was given a second chance–the design of the elevator clearly follows the trademark Tillotson design, whether copied by some one or built by the original contractor.

I wonder if the original repair destroyed the structural integrity of the elevator, and Grain Storage Construction was brought in to replace two of the bins. We know it was a later job because of the 1959 date on the manhole covers. Unfortunately, I made my visit on a Saturday, and the co-op was closed, so there was no one there to ask.

It is a beautiful, functional elevator today. It stands beside the older Mayer-Osborn elevator, which is also clearly in use sixty years after it was built. Both elevators had problems during construction, but the capacity was urgently needed, so both projects were finished. How the Tillotson elevator ultimately became a Grain Construction Company branded elevator is a mystery we will try to solve in a future post.

DSC_0427

Elevator operators once implicated labor activists in mysterious explosions

Evevator test003

A 1920 Department of Agriculture experiment showing that accumulations of grain dust would ignite under the right conditions

Story by Kristen Cart

Elevator fires have been a great concern since the days when Charles H. Tillotson first built wooden elevators with his army of carpenters at the beginning of what would become the family business.

When elevators started to randomly ignite and explode in the early twentieth century, suspicions ran rampant.

Shortly after 1900, labor violence was on the rise, and businesses had reason to be worried.

In the Midwest, elevator owners suspected the labor unionist Industrial Workers of the World (IWW), or Wobblies, had committed acts of sabotage, torching the structures to make their anarchistic point.

Evevator test004

Then, cooler heads prevailed as engineers found a scientific explanation.

Using a scale model in the manner of a college lab experiment, the United States Department of Agriculture demonstrated that grain dust would ignite and explode under the right conditions, leaving destruction and injury in its wake.

The Wobblies were off the hook.

The Tillotson elevator in Boxholm, Iowa, afforded unique photographic possibilities

DSC_0535Story and photos by Kristen Cart

The Boxholm elevator located in central Iowa was an intriguing destination, particularly since I had knowingly passed it by, missing it by a few miles on more than one trip. It became imperative to make the detour to see it. I was glad I did, since the elevator made beautiful pictures on that early summer day. I used a wide-angle lens that added pronounced distortion to the scene, causing the buildings on the edges to lean in dramatically. But the leaning lines pointed to the beautifully clouded sky.

You can use a wide-angle lens to include more of the scene from close quarters than would be possible with another lens, but you forfeit realism. This is not a problem for certain artistic photos, but it is not ideal for documentary shots. When photographing buildings where you want to preserve parallel lines, you must stand farther away and use a longer focal-length lens. At Boxholm, I did not have that option.

DSC_0547

Wide-angle lens distortion is maximized in this view.

At extremely close quarters, the wide-angle lens exaggerates height and adds drama. But the distortion becomes more pronounced.

The Tillotson Construction Company of Omaha, Neb., built the elevator in 1955. An annex stands beside it, and an old wooden feed mill is beside that. A much newer elevator with the West Central logo was built later, after it became customary to leave the concrete plain, without the white finish.

DSC_0563

A more conventional view of the elevator complex.

The specifications for the Boxholm elevator are among the Tillotson Company construction records. We learned some details about the elevator from a few stray sources before my visit; for instance, the elevator has exactly 96 light bulbs installed. Its construction followed the Drummond plan. Other projects using the same architectural plan were the elevators at Waverly, Neb., and Lahoma and Drummond, Okla.

Specifications

Capacity per plans (with Dock): 199,400 bushels

Capacity per foot of height: 2,002 bushels

Reinforced concrete per plans (total): 1,797 cubic yards

Plain concrete (3″ hoppers): 33 cubic yards

Reinforcing steel per plans (includes jack rods): 85.71 tons

Average steel per cubic yard reinforced concrete: 95.4 pounds

Steel and reinforced concrete itemized per plans:

Below main slab: 6,861 pounds steel, 59.2 cubic yards concrete

Main slab: 25,603 pounds steel, 202 cubic yards concrete

Drawform walls: 103,192 pounds steel, 1,295 cubic yards concrete

Driveway and Work floor : 3,820 pounds steel, 23.8 cubic yards concrete

Deep bin bottoms (including columns): 7,271 pounds steel, 39.3 cubic yards concrete

Overhead Bin bottoms: 6,040 pounds steel, 27.6 cubic yards concrete

Bin roof and Extension Roofs: 7,210 pounds steel, 41.7 cubic yards concrete

Scale floor (or garner complete): 160 pounds steel, 2.5 cubic yards concrete

Cupola walls (including leg & head): 7,257 pounds steel, 76 cubic yards concrete

Distributor floor: 1,560 pound steel, 9.4 cubic yards concrete

Cupola roof: 2,147 pounds steel, 15.6 cubic yards concrete

Misc. (track sink, steps, etc.): 173 pounds steel, 3.5 cubic yards concrete

Attached driveway: none

Bridge and/or Tunnel: none

Pit Liner–plain: 16 cubic yards concrete

Drier Bin Bottom: 134 pounds steel, 1.3 cubic yards concrete

Coffer Dam, Cleaner Floor: Wood

Remarks: 10 Bin Hot spot; 8 Bin Aeration tubes; Dryer bin

DSC_0541

The rounded headhouse is a reliable indicator of a Tillotson elevator

Construction details

Like Waverly: construction details were identical to Waverly and not listed separately in the records.

Main slab dimensions (drive length first dimension): 56 1/2′ x 70′

Main slab area (actual outside on ground): 3,850 square feet

Weight reinforced (total) concrete (4000 pounds per cubic yard plus steel): 3,747 tons

Weight plain concrete (hoppers; 4000 pounds per cubic yard): 98 tons

Weight hopper fill sand (3000 pounds per cubic yard): 732 tons

Weight of grain (at 60 pounds per bushel): 5,982 tons

Weight of structural steel and machinery: 20 tons

Gross weight loaded: 10,579 tons

Bearing pressure: 2.75 tons per square foot

Main slab thickness: 24″ with 3″ pile cap

Main slab steel: straight #9 at 7″ spacing

Tank steel and bottom (round tanks): #4 at 12″ spacing

Lineal feet of drawform walls & extension: 606′

Height of drawform walls: 120′

Pit depth below main slab: 15’3″

Cupola dimensions (outside width x length x height): 22 1/4′ x 48 1/2′ x 35′

Pulley centers: 160.75′

Number of legs: 1

Distributor floor: yes

Track sink: yes

Full basement: yes

Electrical room: yes

Driveway width clear: 13′

Dump grate size: 2 at 9′ x 5′ and 9′ x 15′

Column under tanks size: 16″ square

Boot legs and head: concrete

DSC_0531Machinery details

Boot pulley: 72″ x 14″ x 4 15/16″

Head pulley: 72″ x 14″ x 2 7/16″

R.P.M. Head pulley: 42

Belt: 335′, 14″ 6 ply Calumet

Cups: 12″ x 6″ at 8″ spacing

Head drive: Howell 40 horsepower [4 circled here]

Theoretical leg capacity (cup manufacturers rating): 8,440 bushels per hour

Actual leg capacity (80% of theoretical rating): 6,750 bushels per hour

Horsepower required for leg (based on actual capacity): 32 horsepower

Man lift: 1 1/2 horsepower Ehr.

Load out scale: 25 Bushel

Load out spout: 10″ diameter

Truck lift: 7 1/2 horsepower Ehr.

Dust collector system: Fan to bin

Cupola spouting: 10″ diameter

Driveway doors: 2 overhead rolling

Conveyor: provision

Remarks

see page 10 (above)
